Saturday, November 25, 2017

PPA SERVER

PPA KabyLark Server
FC5 Chassis





FC10 Chassis


PPA Serve in FC5 or FC10 Chassis,
This server is the top grade server of the world so far,
Fine tuning with Linear PSU & OCXO module,
Best performance for the Audio & Visual server.






Full Linear power supply,
Offer 120V or 220V AC power line input.
Bundle with TZ YUN top grade DC cables.






With full PPA OCXO module modified,
This server without any digital harshness,
Sounds just like a true analog equipment.




ASUS H270M-PLUS Main Board with kabyLark i7 7700 CPU,
This server was designed and fine tuning for the Win10,
A clean Win10 offered the natural & balance sound quality,
It is no optimized soft ware needed,
Some optimized soft ware may cause unstable or unbalance frequency response.










128G PCIE SSD as OS SSD,
Modified with PPA OCXO module




480G SATA SSD as MUSIC SSD,
Modified with PPA OCXO module.




Lan Card on the Main Board has been modified with PPA OCXO module,
With this top grade OCXO module,
Lan Card on the Main Board is much better than any audio grade Lan Card.
Saving your money and get best sound quality with on line streaming and dual PC mode.



PPA V5 Card with 4 x USB slot,
Modified with PPA OCXO module & audio grade capacitors.




Layout ,
FC5 & FC10 server with the same layout



FC10 server is US$4990 including :

FC10 chassis

i7 7700 ES CPU

ASUS H270M main board
2 x 4G DDR4
12V pico
128G M2 PCIE SSD as OS disk
512G M2 PCIE SSD as MUSIC disk
V5 USB card
External 12V + 5V Linear PSU out put with 1M DC cable
External 2 x SATA ports with 2 x 1M SATA cable

OCXO Modified with OSSSD, Music SSD ,V5 card , Lan card on the main board.
Bundle with Win10 trial version for testing.







FC10 server with extension bracket and Separate 12V + 5V Linear PSU inside,Offer SATA ports & LPSU for external DVD-ROM or HHD , SSD input.
Good for the CD-Ripping & Music Files transfer.

Bundle with :
External 12V + 5V Linear PSU out put with 1M DC cable

External 2 x SATA ports with 2 x 1M SATA cable








FC5 server is US$4490 including:
FC5 chassis
i7 7700 ES CPU
ASUS H270M main board
2 x 4G DDR4
12V pico
128G M2 PCIE SSD as OS disk
512G M2 PCIE SSD as MUSIC disk
V5 USB card

OCXO Modified with OSSSD, Music SSD ,V5 card , Lan card on the main board.
Bundle with Win10 trial version for testing.




EC10 / FC5 server as control PC is US$4490 including:
FC5 chassis
i7 7700 ES CPU
ASUS H270M main board
2 x 4G DDR4
12V pico
128G M2 PCIE SSD as OS disk
512G M2 PCIE SSD as MUSIC disk


External 12V + 5V Linear PSU out put with 1M DC cable
External 2 x SATA ports with 2 x 1M SATA cable

OCXO Modified with OSSSD, Music SSD , Lan card on the main board.
Bundle with Win10 trial version for testing.






EC10 / FC5 server as audio PC / NAA is US$3990 including:
FC10 / FC5 chassis
Pentium G4600 CPU
ASUS H270M main board
2 x 4G DDR4
12V pico
128G M2 PCIE SSD as OS disk
V5 card




OCXO Modified with OS SSD, V5 card , Lan card on the main board.
Bundle with Win10 trial version for testing.


Tuesday, August 15, 2017

COAXIAL /CLOCK Cables


TZ YUN "Silver" Reference Clock / Coaxial cable



TZ YUN "Silver" Reference Coaxial / Clock cable,
Length 1M.





Sliver plated conductor with super band wide up to 50MHz,
Supreme quality for Coaxial or Clock connections









Free RCA adapter include.

US$499 including free shipping world wide

Please email for the paypal invoice
ppastudio@yahoo.com.tw




TZ YUN "Platinum" Reference Clock / Coaxial cable
Aluninum Box include









Free RCA adapter





US$699 including free shipping world wide



Please email for the paypal invoice

ppastudio@yahoo.com.tw




Friday, May 13, 2016

Streamer


Streamer

15th/Aug./2016  Upgrade

Please refer to the user's feedback

Both 44.1 and 48 khz clocks works ok so far.

I'm using AES/EBU connection to another DAC (with AK4399 chip).
I notice rather big resolution and soundstage,
on some tracks I'd say it's huge.
Lot of air. Dynamic range is ok.
No harshness. Very impressive vocal, thundering bass.
Cann't say much about the depth of the soundstage,
because my TH900 headphones doesn't have the feature to render the depth(not like Sennheiser HD 800).

Will try to compare with the streamer's own DAC later.




Decided to stay with internal dac of the streamer.
The reason is that there's no harshness.
My old dac on AK4399 had big resolution but also some instruments sounded sharply.
In addition all musical instruments have 3d dimension on the streamer.
Very natural timbres.
Marvelously tasty piano.
Impressive, emotional vocal.
Cann't say much about the depth of the soundstage because it's not the strong point of my TH900 headphones.
The one thing I'd wish is to slightly lower the tonal balance.
Still, thank you Paul,
excellent piece for its money!
My dac was much more expensive.
Hope 3 seconds drops in the end of tracks and no option to play only one directory will be solved by the software developer.




$USD1499 plus $USD100 shipping



This Streamer bundle with a high quality DSD DAC,
Could playing DSD music with an integrated amplifier.
It is the most easy & cheap way to play DSD music.



AC 220V or 110V input ,
Digital Output : AES/EBU , SPDIF , OPT.
Analog Output : RCA ( unbalance )





Support NAS, USB HHD , USB Stick , SD card in FAT or NTFS format



Remote control



Cell phone remote APP,
Android & iPhone.
Android APP download:






  • Support format
  • WAV
  • WAV : 16bit - 44.1K / 48K / 88.2K / 96K / 176.4K / 192K
  • WAV : 24bit - 44.1K / 48K / 88.2K / 96K / 176.4K / 192K
  • WAV : 32bit - 44.1K / 48K / 88.2K / 96K / 176.4K / 192K
  • float & integer
  • WAV DTS
  • WAV + CUE
  •
  • APE
  • APE  : 16bit -  44.1K / 48K / 88.2K / 96K / 176.4K / 192K   (fast & normal & high & (extra high to 96K)
  • APE  : 24bit -  44.1K / 48K / 88.2K / 96K / 176.4K / 192K
  • fast & normal & high & (extra high to 96K)
  • MAC_3.96、3.97、3.98、3.99、4.01
  • TAOBAO  APE
  • APE + CUE
  •
  • FLAC
  • FLAC : 16bit -  44.1K / 48K / 88.2K / 96K / 176.4K / 192K
  • FLAC : 24bit -  44.1K / 48K / 88.2K / 96K / 176.4K / 192K
  • FLAC + CUE
  •
  • DSD (Bundle dual AK4495SEQ DAC for DSD64,DSD128)
  • DSF : DSD64 / 2.822400MHz ,1bit DoP  or source code
  • DSF : DSD128 / 5.644800MHz , source code
  • DFF DSD64 / 2.822400MHz ,1bit DoP or source code
  • DFF : DSD128 / 5.644800MHz , source code
  • DSD ISO:
  • non com. DST ISO playing ,1bit DoP or source code
  •
  • MP3
  •
  • ALAC ,AIFF






  • 1. PPA modified Dual AK4495SEQ DAC inside.
    2. PPA OCXO module inside.
    3. 3 x Talema power transformer inside.
    4. High performance separated regulator modules inside.
    5. TZ YUN high end grade power cables inside.
    6. PPA  suspension system

    Wednesday, May 4, 2016

    TF to SATA adapter, CF to SATA adapter

    TF to SATA adapter
    TF adapter sound close to the CF adapter and with performance close to the SSD.

    Compatible with latest main board or earlier main board.


    Recommend to use TF adapter as OS disk,
    As CF adapter is not compatible 5th generation & after CPU,
    TF adapter is the replacement of CF adpter.

    Recommend to use 4 x 8G TF cards.
    Offer OCXO version only,
    OCXO need much more current than TCXO,
    Requires single 5V/3A power supply for an OCXO TF adapter.



    8 x 64G TF card as a 512G SSD is too slow for the music disk,
    It is not recommend for the music disk.



    Loading speed is much slower to regular SSD,
    Reading speed is compatible with 1080P video playing.



    US$499 with one year warranty and free world shipping.

    Please note : TF cards is not include!

    Please email for the paypal invoice.

    ppastudio@yahoo.com.tw





    CF to SATA adapter

    CF is much slower to SSD,
    These CF to SATA adapter offer to who know the CF's performance only.
    It is no return & no refund.
    Offer one year warranty.

    TCXO CF to SATA adapter ,
    Standard SSD fixing holes could mount with SSD bracket.
    Clock module is compatible with my SSD board.
    $USD129.



    OCXO CF to SATA adapter ,
    Standard SSD fixing holes could mount with SSD bracket.
    Clock module is compatible with my SSD board.
    $USD429.


    I accept paypal & T/T,
    Please email for the paypal invoice.

    ppastudio@yahoo.com.tw









    Sunday, July 5, 2015

    AUDIO GRADE NAS, ROUTER , SWITCH & 10M REFERENCE CLOCK UNIT

    10M Master reference OCXO clock unit


    Master reference 10MHz OCXO clock unit for the Esoteric,dCS,Aurender.............

    According to the user's feed back,
    The sound quality of this 10M master clock unit is between Esoteric G01 & G02.

    Offer 2 x 10M clock output ,
    Ideal for the 2 x 10M switch with double run.
    1 x 10M switch + DAC / Streamer is also fine.

    Power request 110V or 220V.





    Free 2 x1M clock cable.







    OCXO Audio Grade Router
    OCXO router is design for the top grade on line streaming source,
    Much wider sound stage & rich detail with full of analog like,
    If add an OCXO switch with OCXO router will be even more better.
    It will be a new experience with on line streaming.

    If your source is from the NAS,
    Add an OCXO switch will be good enough.
    OCXO router + OCXO switch or dual OCXO switch is batter but
    not worth the costs.

    As these products are the top grade equipment,
    Better AC power cord & Lan cable for theses equipment is
    needed for the sound quality.



    D-Link DIR-879 AC1900 EXO Wi-Fi Router
    http://us.dlink.com/products/connect/ac1900-wi-fi-router-2/
    12V/ 2A power supply via 1.3mm / 3.5mm DC jack




    12V power supply & Clock unit,
    120V or 220V AC input.
    Power cord is not include,
    Recommend to use Audio Grade power cord for this unit.
    Offer  OCXO version only.


    OCXO module is inside the chassis of LPSU,
    Router need a clock cable & a 2.1mm DC cable connect from the  LPSU unit.
    Free accessory



    60cm 2.1mm DC power cable


    Offer 1 year warranty,
    Burned by higher supply voltage or disassemble is not include.
    Warranty stick broken is no warranty also.

    Offer return within 1 month,
    No return & no refund after 1 month.
    Refund done after received the item,
    Return postage is on buyer side.


    US$999 including free shipping world wide.
    Please email for the paypal invoice.
    ppastudio@yahoo.com.tw



    Audio Grade Switch

    Connection



    Double Run Connection is for 2 x TCXO switch or 2 x OCXO switch,
    TCXO switch + OCXO switch is not recommend.
    Single OCXO switch is better than  TCXO switch + OCXO switch.

    User's feedback
    The switch arrived yesterday - it sounds amazing!!
    Much better than I expected.
    How long will it take to fully burn in and warm up?





    D-Link 8ports 10/100/1000Mbps Switch,
    (10M external master clock input)



    This switch without internal clock,
    Accept 10M master clock input only.
    This switch won't work without external clock input.
    Compatible with Teac , Esoteric 10M master clock unit.

    US$349 including free shipping world wide








    D-Link 8ports 10/100/1000Mbps TCXO Switch










    Modified with TCXO module & audio grade capacitor.

    Power require 5V/ 1A min.,
    Bundle with 5V/ 1A SMPS AC adapter.
    Recommend to use 5V / 1.5A LPSU for the better sound quality.

    Offer 1 year warranty,
    Burned by higher supply voltage or disassemble is not include.
    Warranty stick broken is no warranty also.

    Offer return within 1 month,
    No return & no refund after 1 month.
    Refund done after received the item,
    Return postage is on buyer side.

    US$219 including free shipping world wide,
    Switch + 60cm Red Lan cable US$319 including Free shipping world wide.

    Please email for the paypal invoice.




    ppastudio@yahoo.com.tw








    Recommend to use LPSU for the Switch ,
    This 2 rails LPSU offer 2 rails on 5V or 9V or 12V output,
    This is a very high quality LPSU  could improve the sound quality.


    2 Rails Linear PSU for Switch & Router


    ppastudio@yahoo.com.tw



    OCXO Switch

    User's feed back
    FM 255 + FM 811


    PPA OCXO Switch with wider sound stage,
    More extension on high & low frequency both,
    Much more solid body .


    Compare with TCXO switch






    OCXO Switch Lite









    OCXO module on the top of  Switch unit,
    Power requirement is 5V / 3A ,
    Supply voltage over 5.25V may burned this switch.


    Please use 5V power supply only.

    Offer one year warranty,
    Burned by high voltage PSU is not include.

    US$549 including free shipping world wide



    Option
    Recommend to use Battery Adapter to powered this switch,
    Powered by an audio grade Linear PSU is also fine.









    8 ports GB Switch with LPSU + OCXO module unit







    Switch unit,
    No clock module inside.



    LPSU & OCXO clock module unit




    Very high quality Linear PSU with 2 rails 5V with true 1.6A output,
    One rail is for OCXO module inside,
    Another rail is 5V for Switch via 3pin XLR socket output.
    Pin1 is ground, Pin3 is 5V ,Pin2 is N.C.



    OCXO module is inside the chassis of LPSU,
    Switch need a clock cable & a 2.1mm DC cable connect from the  LPSU unit.




    Offer 1 year warranty,
    Burned by higher supply voltage or disassemble is not include.
    Warranty stick broken is no warranty also.

    Offer return within 1 month,
    No return & no refund after 1 month.
    Refund done after received the item,
    Return postage is on buyer side.


    $USD799 including free shipping world wide

    Please email for the paypal invoice.
    ppastudio@yahoo.com.tw


    Free  Accessory


    60CM TZ YUN dc power cable,


    Option
    TZ YUN Red Lan cable,
    60cm $USD199,
    1M $USD299.

    Please email for the paypal invoice.

    ppastudio@yahoo.com.tw



    OCXO Gigabit Smart Managed Switch with 4 Gigabit RJ45/SFP COMBO ports

              D-Link DGS-1210-28








    This switch has 4 x clock on board,

    And modified with PPA OCXO module



    D-Link 1210-20,
    Same with 1210-28 but less width & ports








    Internal SMPS is disable.
    Accept 12V / 3A PSU via 2.1mm DC jack only.

    Higher supply voltage may burned this switch,
    Please use qualifier PSU for this switch.
    PSU is not include and recommend to use an audio grade Linear PSU for the best sound quality.


    DGS-1210-28 or DGS-1210-20 offer one year warranty,
    Warranty is not include the higher supply voltage burned this switch .

    US$799 including free world wide shipping.
    Please email for the paypal invoice.

    ppastudio@yahoo.com.tw


    Special offer

    PPA 12V / 3.2A Linear PSU for this switch.
    Switch with LPSU & 1M DC cable is US$1090 including free shipping.
